Technical Data
Capacity:
Up to 120 Pallets/h; vertically double-strapped
(with package height spread <+ - 200 mm)
Electrical Power:
Operating Voltage: 400 V , 50 Hz,
3 PH / N / PE,
Control Voltage: 24 V DC
Total Connection: 4 KVA
Strapping:
Strap Types: Standard machine grade
PP and PET straps
Strap Sizes: Width: 9.5 - 16.0 mm
Thickness: 0.4 - 0.75mm
Break Strength: 2,200 - 7,500 N
Strap Tension: 250 - 2,500 N
infinitely adjustable
Strap Feed: 4.2 m/sec.
Sealing Head:
MOSCA friction-weld sealing head
Weight: 1,200 kg
